Product Description
Key Features & Performance
Quick Connection: The brush mechanism is quickly connected to the skid steer loader, allowing installation and removal within 2 minutes. The brush features floating and self-adjusting functions. The connection frame adopts a box-type structure with high strength and smooth movement. The sweeping frame uses a single-beam structure, which is lightweight and highly durable. The product is equipped with 3 lifting rings for easy transportation and handling.
|
Technical Parameters
|
|
Parameter
|
020160
|
020172
|
020184
|
|
Length (mm)
|
1625
|
1625
|
1625
|
|
Width (mm)
|
1804
|
2163
|
2435
|
|
Height (mm)
|
870
|
870
|
870
|
|
Weight (incl. mount, kg)
|
500
|
545
|
575
|
|
Sweeping Width (mm)
|
1500
|
1800
|
2100
|
|
Deflection Angle ()
|
30
|
30
|
30
|
|
Sweeping Width at 30 (mm)
|
1250
|
1550
|
1850
|
|
Roller Diameter (mm)
|
800
|
800
|
800
|
|
Max. Pressure (MPa)
|
21
|
21
|
21
|
|
Flow Rate (L/min)
|
70-85
|
80-100
|
80-100
|
|
Operating Voltage (V)
|
DC12/24
|
DC12/24
|
DC12/24
|
|
Compatible Loaders
|
Skid Steer/Small Loaders
|
